Easun Reyrolle
2TJM70/1P
Single Pole Normal Inverse IDMT relay in horizontal 2/3V vedette draw out case,
case cover colour black,
5A with a setting range of 10-40% and a tripping
time of 1.3 seconds at 10 times of setting current
2TJM70/3P
Three Pole Normal Inverse IDMT relay in horizontal 2V (H) vedette draw out case,
case cover colour black,
5A with a setting range of 50-200%
and a tripping time of 1.3 seconds at 10 times of setting current
2TJM71/3P
Three Pole Normal Inverse IDMT relay in horizontal
2V (H) vedette draw-out case, case cover colour black,
5A with a setting range of 50-200%
and a tripping time of 1.3 seconds at 10 times of setting current
fitted with instantaneous high set element MCAA with a setting range of 400% - 1600%
India
Alstom / Areva
IDMT E/F Relay
CDG11
CDG14
CDG16
IDMT O/C Relay
CDG31
CDG34
CDG36
India
Delab
IDMT E/F Relay
TM-8350s
Chinese Version
Combined O/C & E/F IDMT Relay
TM-9000s
ASHIDA Numerical Protection Relays
ASHIDA 電子式保護繼電器
- Wide range of current and time settings
- Back-lit LCD display for settings and fault / load currents
- Wide range AC/DC auxiliary supply
- Selectable operating characteristics (NI-3, NI1.3, VI, EI, LI & DT)
to IEC60255-151:2009-08 Annex A
ADR111C
1 pole earth fault protection relay, fix type,
auxiliary supply 18-250V AC/DC( 20%)
ADR141C
4 pole (3 OC + 1 EF) protection relay, fix type,
auxiliary supply 18-250V AC/DC(± 20%)
ADR111A
1 pole earth fault protection relay, drawout type,
auxiliary supply 18-250V AC/DC(± 20%) with IP cover
ADR211A
1 pole earth fault protection relay, drawout type,
auxiliary supply 18-250V AC/DC(± 20%) with USB at front
and RS485/422 at rear for communication with IP cover
ADR141A
4 pole (3 OC + 1 EF) protection relay,
drawout type, auxiliary supply 18-250V AC/DC(± 20%) with IP cover
ADR241A
4 pole (3 OC + 1 EF) protection relay,
drawout type, auxiliary supply 18-250V AC/DC(± 20%) with USB at front
and RS485/422 at rear for communication with IP cover
Mikro Protection Relays 美高牌保護繼電器
MK2200-240AD
Combined numerical IDMT overcurrent and earth-fault relay, with RS485 and selectable time-currrent characteristics of NI-3/10, VI, EI, LI and DT, for 84-265V AC or 110-340V DC
auxiliary supply, panel mount.
MK2200-150D
Combined numerical IDMT overcurrent and earth-fault relay, with RS485 and selectable time-currrent characteristics of NI-3/10, VI, EI, LI and DT, for 24-150V DC auxiliary supply, panel mount.
MK1000A-240A
Combined numerical IDMT overcurrent and earth-fault relay, with selectable time-current characteristics of NI-3/10, NI-1.3/10, VI, EI, LI and DT, for 198-265V AC auxiliary supply,
DIN 96x96 panel mount.
MK1000A-150D
Combined numerical IDMT overcurrent and earth-fault relay, with selectable time-currrent characteristics of NI-3/10, NI-1.3/10, VI, EI, LI and DT, for 24-150V DC auxiliary supply,
DIN 96x96 panel mount.
MK233A-240A
Numerical IDMT overcurrent relay, with selectable time-current characteristics of NI-3/10, NI-1.3/10, VI, EI, LI and DT, for 198-265V AC auxiliary supply, DIN 96x96 panel mount.
MK232A-240A
Numerical IDMT earth fault relay, with selectable time-current characteristics of NI-3/10, NI-1.3/10, VI, EI, LI and DT, for 198-265V AC auxiliary supply, DIN 96x96 panel mount.
MK232A-150D
Numerical IDMT earth fault relay, with selectable time-current characteristics of NI-3/10, NI-1.3/10, VI, EI, LI and DT, for 24-150VDC auxiliary supply, DIN 96x96 panel mount.
MK201A-240A
Numerical definite time earth fault relay, for 198-265V AC auxiliary supply, DIN 96x96 panel mount.
RDR01
IDMT Earth Fault Relay
RDR04
IDMT Over Current & Earth Fault Relay
